„MERCUSYS“ 300 Mbps daugiarežimis belaidis N maršrutizatorius

• Fast Wi-Fi for Daily Life— MW302R provides fast and stable connections to meet all your network needs with speeds of up to 300 Mbps


• Broader Coverage— Equipped with high gain external antennas to deliver strong Wi-Fi signals to every corner of your home


• Multi-Mode— Four modes in one device to satisfy all application scenarios


• Easy installation— Intuitive webpage guides you through the setup process in minutes


• Active Parental Controls— Establish appropriate access policies to protect children with responsible, safe internet access


• Compatible with IPv6 (Internet Protocol version 6)

Wireless

Wireless Standards

IEEE 802.11b/g/n

Frequency

2.4-2.4835GHz

WiFi Speeds

• 11n: Up to 300Mbps (Dynamic)

• 11g: Up to 54Mbps (Dynamic)

• 11b: Up to 11Mbps (Dynamic)

Reception Sensitivity

• 270M: -73dBm@10% PER

• 130M: -75dBm@10% PER

• 54M: -77dBm@10% PER

• 11M: -90dBm@10% PER

• 6 M: -94dBm@10% PER

• 1 M: -96dBm@10% PER

Transmission Power

<20dBm (EIRP)

Wireless Security

WPA-PSK / WPA2-PSK

Wireless Functions

Enable/Disable Wireless Radio, WDS Bridging

Software

WAN Type

Dynamic IP/Static IP/PPPoE/PPTP/L2TP

Management

Access Control, Local Management, Remote Management

DHCP

Server

Port Forwarding

Virtual Server, UPnP, DMZ

Firewall Security

IP and MAC Address Binding

Protocols

IPv4, IPv6

Guest Network

2.4GHz Guest Network

Hardware

Dimensions

114 mm × 94 mm × 26 mm

Button

Reset Button

External Power Supply

5V/0.6A

Antenna Type

2 * 5dBi

Ethernet Ports

2*10/100Mbps LAN Ports

1*10/100Mbps WAN Port

Others

Package Contents

300Mbps Wireless N Router ( MW302R )

Power Adapter

Quick Installation Guide

Ethernet Cable

Environment

• Operating Temperature: 0°C~40°C (32°F~104°F)

• Storage Temperature: -40°C~70°C (-40°F~158°F)

• Operating Humidity: 10%~90% Non-Condensing

• Storage Humidity: 5%~90% Non-Condensing
