Edimax N300 wireless router

Edimax N300. Wi-Fi band: Single-band (2.4 GHz), Top Wi-Fi standard: Wi-Fi 4 (802.11n), WLAN data transfer rate (max): 300 Mbit/s. Ethernet LAN interface type: Fast Ethernet, Ethernet LAN data rates: 10,100 Mbit/s, Cabling technology: 10/100Base-T(X). Security algorithms: WEP, WPA, WPA2, WPA2-PSK, WPS, Firewall security: SPI Firewall, IP and MAC Address Binding, Wireless MAC Filtering. Supported network protocols: Dynamic IP, Static IP, PPPoE, IPv4. Product type: Tabletop router, Product colour: Black, LED indicators: Power

Wi-Fi 4 You.
The Significant High-Gain, High-Performance N300 Router.

The BR-6428nS V5 adopts the most popular wireless standard: IEEE 802.11n, which is also identified as generation Wi-Fi 4 and provides significantly improved coverage with its high-gain antennas. Operating as a router, access point, range extender or WISP, the BR-6428nS V5's flexibility meets the demands of most networking applications. The smart Setup wizard makes installation as easy as a few clicks. Impressive performance makes the BR-6428nS V5 an excellent solution for home or small office environments..

4-in-1 Wi-Fi Router, Access Point, Range Extender, and WISP
The BR-6428nS V5 can work as 4 major modes for wireless networking, including router, access point, range extender, and WISP modes. No matter you want to use it simply over a router for Internet sharing, as an access point for transferring wired connection into wireless network, extending the signals to be a range extender, or sharing a wireless Internet connection with all your devices, just switch it for your network environment by using the smart setup wizard.

Easy Setup and Use
for smart, automatic and quick installation with no CD required.

BR-6428nS V5 makes it easy to do more with your digital devices. Or, use Push 'WPS' Connect to add devices to your Wi-Fi network with a push of a button. And the simple browser-based installation with no CD makes router installation easy using an iPad, tablet, smartphone, or computer.

High-Gain Antennas for Maximum Coverage
Employing two external high-gain fixed antennas, the BR-6428nS V5 can increase signal strength and enhances the range of your Wi-Fi network. It also helps strengthen signal penetration through walls and floors across your home or office.

Guest Network
The BR-6428nS supports a guest network to provide connectivity while isolating guests from your primary network. Makes it easier for your guest to get connected and keep your networking devices stay in greater security.

*Router mode only.

WAN connection

Ethernet WAN: Yes
DSL WAN: No
SIM card slot: No
3G/4G USB modem compatibility: No

Wireless LAN features

Wi-Fi band: Single-band (2.4 GHz)
Top Wi-Fi standard: Wi-Fi 4 (802.11n)
WLAN data transfer rate (max): 300 Mbit/s
Wi-Fi standards: 802.11b, 802.11g, Wi-Fi 4 (802.11n)

Network

Ethernet LAN: Yes
Ethernet LAN interface type: Fast Ethernet
Ethernet LAN data rates: 10,100 Mbit/s
Cabling technology: 10/100Base-T(X)
Networking standards: IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Port forwarding: Yes
Dynamic DNS (DDNS): Yes
Receiver sensitivity: 11g (11Mbps): -79 ±2dBm, 11g (54Mbps): ‐68±2dBm, 11n (20MHz, MCS7): ‐67±2dBm, 11n (40MHz, MCS7): ‐64±2dBm

Mobile network

3G: No
4G: No

Ports & interfaces

Ethernet LAN (RJ-45) ports: 5
USB port: No
Memory card slot(s): No
DC-in jack: Yes

Management features

Web-based management: Yes
Reset button: Yes
WPS push button: Yes

Security

Security algorithms: WEP, WPA, WPA2, WPA2-PSK, WPS
Firewall: Yes
Firewall security: SPI Firewall, IP and MAC Address Binding, Wireless MAC Filtering
Guest access: Yes
Access Control List (ACL): Yes
Stateful Packet Inspection (SPI): Yes
Filtering: Yes
MAC address filtering: Yes
System event log: Yes
DMZ support: Yes

Protocols

DHCP client: Yes
DHCP server: Yes
Universal Plug and Play (UPnP): Yes
Supported network protocols: Dynamic IP, Static IP, PPPoE, IPv4

Design

Product colour: Black
LED indicators: Power
Product type: Tabletop router

Certificates

Certification: CE, RoHS

Antenna

Antenna design: External
Antennas quantity: 2
Transmit power: 16 dBmW

Features

Internal memory: 8 MB
Flash memory: 2 MB
Firmware upgradeable: Yes

Power

Power source type: DC
Output voltage: 9 V
Output current: 0.4 A

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 10 - 90%

Weight & dimensions

Width: 153.8 mm
Depth: 107 mm
Height: 25 mm
Weight: 150 g

Packaging data

Package type: Box
Number of products included: 1 pc(s)

Logistics data

Harmonized System (HS) code: 85176990
