CORE REACTOR II
IMPROVE YOUR CORE, ENHANCE YOUR PERFORMANCE
CORE REACTOR II is a top-performing power supply unit designed for ATX 3.0 & ATX 3.1 compliance with a modular cable design and an 80 PLUS GOLD certification. These power supplies thrive in high-performance scenarios like servers or workstation setups, where a lot of power is needed.
Next-Gen Ready - ATX 3.0 & ATX 3.1 COMPLIANT
CORE REACTOR II series power supply units meet Intel ATX 3.0 & ATX 3.1 design guide specifications and feature a 12VHPWR connector. By upgrading to an ATX 3.0 & ATX 3.1-compliant power supply, you'll be fully equipped for the upcoming wave of high-performance components. A must for the modern gamer, creator, or AI developer. Stay ahead of the curve by upgrading to an ATX 3.0 & ATX 3.1 PSU, the new standard in PC hardware.
Certified GOLD Efficiency
CORE REACTOR II units recieved 80 PLUS GOLD certifications for efficiency, achieving up to 91.40% (115V) efficiency at 50% load. It comes in 1200W, 1000W, 850W, 750W, and 650W models for varying user needs and scenarios. It's the perfect PSU for mid-to-high level components, including the latest CPUs and GPUs.
Intelligent Fan-Curve Design
The intelligent fan curve ensures quiet operation, even under full power load. By starting the fan at a low RPM, fan performance is both enhanced and extended, thereby increasing the power supply unit's lifespan.
Premium all 105°C Japanese Capacitors
CORE REACTOR II features top-tier 105°C Japanese capacitors, ensuring exceptional stability and reliability of the PSU for many years of dependable performance.
PEAK PERFORMANCE AND RELIABILITY
All XPG ATX 3.0 and ATX 3.1 power supplies are designed to support up to 235% power excursion, enabling the system to handle sudden power spikes, ensuring stability, and preventing crashes during intense workloads like gaming, rendering, and data processing.
| AC įėjimo dažnis | 50/60 Hz |
| AC įėjimo įtampa | 100 - 240 V |
| Atitikties sertifikatai | "Norma Oficial Mexicana" (NOM)/BSMI/CB/CE/China Compulsory Certification (CCC)/cTUVus/EAC/Federalinė ryšių komisija (FCC)/RCM/UKCA |
| ATX maitinimo jungtis | Taip |
| ATX maitinimo jungtis (12 + 4 kaištiniai kontaktai) | Taip |
| ATX versija | 3.0 |
| Aukštis | 86 mm |
| Aušinimo padengimo tipas | FDB |
| Aušinimo tipas | Aktyvus |
| Bendroji galia | 1000 W |
| Bruto svoris | 4 kg |
| Didžiausia išėjimo įtampa (+12 V) | 83.5 A |
| Didžiausia išėjimo įtampa (+12 VSB) | 3 A |
| Didžiausia išėjimo įtampa (+3,3 V) | 22 A |
| Didžiausia išėjimo įtampa (+5 V) | 22 A |
| Didžiausia išėjimo įtampa (-12 V) | 0.3 A |
| EPS maitinimo jungtis (8-kaisčiai) | Taip |
| EPS versija | 2.92 |
| Galios koeficientas | 0.99 |
| Ilgis | 150 mm |
| Maitinimo apsaugos ypatybės | Apsauga nuo per didelės įtampos/Apsauga nuo perkaitimo/Minimaliosios įtampos apsauga/Surge & inrush protection (SIP)/Trumpasis jungimas/Viršijus galią/Viršijus nuolatinę srovę |
| Maitinimo bloko (PSU) formos koeficientas | ATX |
| Model name | CORE REACTOR II |
| Motininės plokštės maitinimo jungtis | 24-pin ATX |
| Neto svoris | 3.05 kg |
| Paketo svoris | 3430 g |
| Pakuotės aukštis | 157 mm |
| Pakuotės gylis | 338 mm |
| Pakuotės plotis | 210 mm |
| Paskirtis | PC |
| PCI "Express" maitinimo jungtys (6 + 2 kontaktai) | 8 |
| Perdavimo laidu tipas | Visiškai modulinis |
| Periferinė (Molex) galios jungtis (4-pin) | 3 |
| Plotis | 160 mm |
| Produkto spalva | Juoda |
| SATA elektros jungčių skaičius | 9 |
| Sertifikatas 80 PLUS | 80 PLUS Gold |
| Shipping Box Depth | 44.5 cm |
| Shipping Box Height | 36.5 cm |
| Shipping Box Weight | 16 kg |
| Shipping Box Width | 34 cm |
| Summary | XPG COREREACTOR II 1000W Power Supply. Total power: 1000 W, AC input voltage: 100 - 240 V, AC input frequency: 50/60 Hz. Motherboard power connector: 24-pin ATX, Cabling type: Fully-Modular. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Cooling type: Active, Fan diameter: 13.5 cm. Compliance certificates: BSMI, CB, CE, China Compulsory Certification (CCC), EAC, Federal Communications Commission (FCC),... |
| Svoris | 1770 g |
| Unit Box Height | 0.215 |
| Unit Box Length | 0.341 |
| Unit Box Width | 0.16 |
| Unit Brutto Volume | 0.01381 cubm |
| Vendor Homepage | https://www.xpg.com/en/xpg/pc-components-core-reactor-ii |
| Ventiliatoriaus skersmuo | 135 mm |
| Ventiliatorių skaičius | 1 ventiliatorius(iai / ių) |
| Vidutinis laikas tarp trikčių (MTBF) | 100000 h |
| Vieneto aukštis | 21.5 cm |
| Vieneto gylis | 34.1 cm |
| Vieneto plotis | 16 cm |
| Vienetų skaičius vienoje siuntimo dėžėje | 4 |
| Įvesties srovė | 13 A |
