ASUS ROG Strix B550-F Žaidimams ATX Pagrindinė plokštė lizdui AM4 su M.2/USB3.2/HDMI/DP
ASUS ROG Strix B550-F Žaidimams ATX Pagrindinė plokštė lizdui AM4 su M.2/USB3.2/HDMI/DP
Garantija
24 mėn.
Pristatymas iš Europos
per 13 - 18*
d. d.
Advance Your Gaming Immersion
ROG Strix B550-F Gaming is PCIe® 4.0-ready and provides the latest connectivity options for supersmooth networking and blisteringly fast file transfers. Audio enhancements give you a massive advantage, allowing you to pick up on the subtlest of cues for a completely immersive gaming experience.
PCIe 4.0-Ready
ROG Strix B550-F Gaming features two M.2 slots, one of which supports the latest PCIe 4.0 standard to provide maximum storage flexibility and the fastest data speeds available via the 3rd Gen AMD Ryzen platform. Both M.2 slots support up to the type 22110 socket and NVM Express® RAID for a performance boost.
All-round Performance
ROG Strix B550-F Gaming provides robust power delivery to fuel Ryzen's cores, comprehensive cooling, and support for faster memory — so it has everything you need to load up your build with high-performance components for playing in the big leagues.
Play Your Own Style
The cyberpunk-inspired aesthetics of ROG Strix B550-F Gaming are accentuated by the bold slashes and cybertext. By pairing your rig with other products from the diverse ROG ecosystem, you can create a fully customized gaming setup that reflects your personal style.
UNDENIABLY ROG STRIX
ROG Strix B550-F Gaming embodies the ROG spirit with eye-catching aesthetics, including the next-generation distorted ROG eye logo and recessed cybertext patterning etched on the I/O shroud. These new designs move ROG Strix boldly into the future, while clearly reflecting the series' gaming roots.
ROG Gives You More
ROG-exclusive software utilities deliver intuitive audio tuning and gaming enhancements that allow you to configure your gaming build the way you want.
UEFI BIOS
The renowned ROG UEFI (BIOS) provides everything you need to configure, tweak, and tune your rig. It offers intelligently simplified options for newcomers to PC DIY, as well as comprehensive features for seasoned veterans.
| Summary: | ASUS ROG STRIX B550-F GAMING. Processor manufacturer: AMD, Processor socket: Socket AM4, Compatible processor series: AMD Ryzen 3000 Series. Supported memory types: DDR4-SDRAM, Maximum internal memory: 128 GB, Memory slots type: DIMM. Supported storage drive interfaces: M.2, SATA III, Supported storage drive types: HDD & SSD, RAID levels: 0, 1, 10. Parallel processing technology support: 2-Way CrossFireX. Ethernet interface type: 2.5 Gigabit Ethernet, LAN controller: Intel I225-V |
| Vendor Homepage: | https://www.asus.com/Motherboards/ROG-STRIX-B550-F-GAMING |
| Category Code: | MBA |
| CnCode: | 84733020 |
| Unit Box Height: | 0.07 |
| Unit Box Length: | 0.34 |
| Unit Box Width: | 0.275 |
| Audio output channels: | 7.1channels |
| Component for: | PC |
| Cooling type: | Active |
| Motherboard chipset: | AMD B550 |
| Motherboard chipset family: | AMD |
| Motherboard form factor: | ATX |
| PC health monitoring: | CPU/Fan |
| Power source type: | ATX |
| Product colour: | Black |
| Windows operating systems supported: | Windows 10/Windows 10 Education/Windows 10 Education x64/Windows 10 Enterprise/Windows 10 Enterprise x64/Windows 10 Home/Windows 10 Home x64/Windows 10 IOT Core/Windows 10 IoT Enterprise/Windows 10 Pro/Windows 10 Pro x64/Windows 10 x64 |
| Compatible processor series: | AMD Ryzen 3000 Series |
| Maximum number of SMP processors: | 1 |
| Processor manufacturer: | AMD |
| Processor socket: | Socket AM4 |
| Supported processor sockets: | Socket AM4 |
| Maximum internal memory: | 128GB |
| Memory slots type: | DIMM |
| Number of memory slots: | 4 |
| Supported memory clock speeds: | 2133/2400/2666/2800/3000/3200/3466/3600/3866/4000/4133/4400/4600MHz |
| Supported memory types: | DDR4-SDRAM |
| Number of HDDs supported: | 6 |
| RAID levels: | 0/1/10 |
| RAID support: | Yes |
| Supported storage drive interfaces: | M.2,SATA III |
| Supported storage drive types: | HDD & SSD |
| On-board graphics card: | No |
| Parallel processing technology support: | 2-Way CrossFireX |
| 12V power connector: | Yes |
| CPU fan connector: | Yes |
| EPS power connector (8-pin): | Yes |
| Number of chassis fan connectors: | 3 |
| Number of EATX power connectors: | 1 |
| Number of SATA III connectors: | 6 |
| Thunderbolt headers: | 1 |
| USB 2.0 connectors: | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors: | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) connectors: | 1 |
| DisplayPort version: | 1.2 |
| DisplayPorts quantity: | 1 |
| Ethernet LAN (RJ-45) ports: | 1 |
| HDMI ports quantity: | 1 |
| HDMI version: | 2.1 |
| Headphone outputs: | 1 |
| Microphone in: | Yes |
| S/PDIF out port: | Yes |
| USB 2.0 ports quantity: | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: | 1 |
| Bluetooth: | Yes |
| Bluetooth version: | 5.0 |
| Ethernet interface type: | 2.5 Gigabit Ethernet |
| Ethernet LAN: | Yes |
| LAN controller: | Intel I225-V |
| Wake-on-LAN ready: | Yes |
| Wi-Fi: | No |
| Number of M.2 (M) slots: | 2 |
| PCI Express slots version: | 3.0/4.0 |
| PCI Express x1 (Gen 3.x) slots: | 3 |
| PCI Express x16 (Gen 3.x) slots: | 1 |
| PCI Express x16 (Gen 4.x) slots: | 1 |
| PCI slots: | 7 |
| BIOS memory size: | 256000Mbit |
| BIOS type: | UEFI AMI |
| Harmonized System (HS) code: | 84733020 |
| Depth: | 244mm |
| Height: | 68mm |
| Width: | 305mm |
| Cables included: | SATA |
| Drivers included: | Yes |
| Manual: | Yes |
| Weight: | 945g |
| Units per Pallet: | 0 |
| Units per Shipping Box: | 4 |
| Unit Calculated Volume: | 0.008323m³ |
| Unit Calculated Weight: | 1.87kg |
