„Sharp MultiSync E509“

Sharp MultiSync E509. Product design: Digital signage flat panel. Display diagonal: 127 cm (50"), Display technology: LCD, Display resolution: 3840 x 2160 pixels, Display brightness: 3501 cd/m², HD type: 4K Ultra HD. Product colour: Black

Professional performance, affordable value

The entry point for professional display solutions, the Sharp MultiSync® E9 Series is designed for modern business environments that need more than a consumer TV can offer. Combining essential features for meeting rooms and digital signage with commercial-grade reliability, the E9 Series delivers crisp UHD resolution, integrated media playback, and 16/7 operation at an accessible price point. A professional matte high-haze panel ensures superior visual performance in this product category, minimising reflections and glare common with glossy panels.

Designed for seamless integration across the wider Sharp display family, the E9 Series shares the same core identity, including the same remote control and device management for a consistent user experience. A robust metal back cover secures product longevity in commercial settings. Whether for presentations, retail signage, or corporate communication, the E9 Series gives you the professional edge without stretching your budget

Display

Panel type: VA
Feature: LED backlight
LED backlighting type: Direct-LED
Display diagonal: 127 cm (50")
Display technology: LCD
Display resolution: 3840 x 2160 pixels
Display brightness: 3501 cd/m²
HD type: 4K Ultra HD
Native aspect ratio: 16:9
Response time: 8 ms
Contrast ratio (typical): 4000:1
Viewing angle, horizontal: 178°
Viewing angle, vertical: 178°
Display number of colours: 1.07 billion colours
Pixel pitch: 0.285 x 0.285 mm
Active display area (W x H): 1096 x 616 mm
Display diagonal (metric): 125.7 cm
Horizontal scan range: 15 - 135 kHz
Vertical scan range: 23 - 76 Hz
Haze rate: 25%

Ports & interfaces

HDMI ports quantity: 2
HDMI input ports quantity: 2
Feature: USB port
USB ports quantity: 2
USB connector type: USB Type-A, USB Type-C
Ethernet LAN (RJ-45) ports: 1
Audio (L/R) in: 1
Audio (L/R) out: 1
Feature: RS-232C

Audio

Feature: Built-in speaker(s)
Number of built-in speakers: 2
RMS rated power: 20 W

Design

Product design: Digital signage flat panel
Placement supported: Indoor
Product colour: Black
Screen shape: Flat
Feature: VESA mounting
Panel mounting interface: 200 x 200 mm
Bezel width (bottom): 1.08 cm
Bezel width (side): 1.08 cm
Bezel width (top): 1.08 cm

Performance

Purpose: Universal

Power

Power consumption (typical): 99 W
Power consumption (standby): 0.5 W
Input voltage: 100 - 240 V
Energy efficiency class (SDR): G
Energy consumption (SDR) per 1000 hours: 90 kWh
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz

Weight & dimensions

Display width: 1120 mm
Display depth: 59.9 mm
Display height: 641 mm
Display weight: 9.2 kg

Packaging data

Package width: 1253 mm
Package depth: 128 mm
Package height: 761 mm
Package weight: 13 kg

Packaging content

Feature: Remote control included
Cables included: AC

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 20 - 80%
Storage temperature (T-T): -20 - 60 °C
Storage relative humidity (H-H): 10 - 80%

Network

Feature: Ethernet LAN
Ethernet LAN data rates: 100 Mbit/s
