„PowerWalker VFI 3000 ICT“ daiktų interneto nepertraukiamo maitinimo šaltinis (UPS)

PowerWalker VFI 3000 ICT IoT. UPS topology: Double-conversion (Online), Output power capacity: 3 kVA, Output power: 3000 W. AC outlet types: C13 coupler, C19 coupler, Power plug: C20 coupler, AC outlets quantity: 9 AC outlet(s). Battery capacity: 9 Ah, Battery voltage: 12 V, Battery recharge time: 3 h. Form factor: Tower, Product colour: Black, Cooling type: Active. Cables included: Input power cable, Output power cable, USB cable

PowerWalker VFI 1000-3000 ICT/ICR IoT series is the next generation of UPS, offering an intuitive App for remote monitoring via cloud. The UPS is quickly setup and easy to maintain, and it provides the ability to review the workflow and troubleshoot instantly - regardless of time and place. This cloud-based monitoring increases the availability and quality of traditional monitoring, while at the same time allowing room for cost reduction, scalability, and trend analysis.

This UPS series utilizes double conversion technology and features unity power factor, ensuring the availability of your mission-critical equipment and providing clean output power to your sensitive loads. Multiple optional accessories such as external battery packs, communication cards and a WLAN adapter enhance the functionality of the UPS.

Stay up to date everywhere and anytime.

Features

UPS topology: Double-conversion (Online)
Output power capacity: 3 kVA
Output power: 3000 W
Waveform: Pure sine
Input operation voltage (min): 160 V
Input operation voltage (max): 300 V
Input frequency: 40/70 Hz
Output operation voltage (min): 200 V
Output operation voltage (max): 240 V
Output voltage regulation: 1%
Response time: 0 ms
Input power factor: 0.99
Output power factor: 1
Crest factor: 3:1
Feature: ECO mode
Feature: Emergency Power Off (EPO)
Output voltage Total Harmonic Distortion (THD): 1%
Input current Total Harmonic Distortion (THD): 5%
Noise level: 50 dB
Power protection features: Overload

Ports & interfaces

AC outlet types: C13 coupler, C19 coupler
Power plug: C20 coupler
AC outlets quantity: 9 AC outlet(s)
Feature: USB port
Feature: Serial interface
Serial interface type: RS-232
Serial ports quantity: 1
Feature: Emergency Power Off (EPO) connector

Battery

Battery capacity: 9 Ah
Battery voltage: 12 V
Number of batteries supported: 6
Battery recharge time: 3 h
Charging current: 1.5 A

Design

Form factor: Tower
Cooling type: Active
Feature: Built-in fan
Product colour: Black
Display type: LCD
LED indicators: Yes

Operational conditions

Operating temperature (T-T): 0 - 45 °C
Operating relative humidity (H-H): 0 - 95%

Packaging content

Cables included: Input power cable, Output power cable, USB cable
Feature: Manual

Weight & dimensions

Width: 192 mm
Depth: 428 mm
Height: 318 mm
Weight: 26.4 kg

Packaging data

Package width: 590 mm
Package depth: 330 mm
Package height: 475 mm
Package weight: 28.9 kg

Logistics data

Harmonized System (HS) code: 85078000
