„Corsair RMe“ serijos RM1200e maitinimo blokas

Corsair RMe Series RM1200e. Total power: 1200 W, AC input voltage: 100 - 240 V, AC input frequency: 47 - 63 Hz. Motherboard power connector: 24-pin ATX, Motherboard power cable length: 61 cm, SATA power cable length: 115,455,800 mm. Purpose: PC, Power supply unit (PSU) form factor: ATX, 80 PLUS certification: 80 PLUS Gold. Product colour: Black, Cooling type: Active, Number of fans: 1 fan(s). Weight: 3.38 kg

CORSAIR RMe Series Fully Modular Low-Noise Power Supplies with ATX 3.1 and PCIe 5.1 compliance provide quiet, reliable power with 80 PLUS Gold efficiency to a wide variety of PC builds.

FULLY MODULAR CABLING
Keep cable clutter down by connecting only the cables your system needs and nothing else. Five universal 8-pin connectors can be used with any 8-pin cable, satisfying all the power needs of modern motherboards and GPUs.

ATX 3.1 CERTIFIED
The ATX 3.1 standard demands a high level of reliability and power efficiency. While many CORSAIR PSUs meet these requirements, RMe Series PSUs are formally certified for ATX 3.1 compliance.

PCIe 5.1 12v-2x6 GPU cable included for use with modern graphics cards such as the NVIDIA® GeForce RTX™ 50 Series.

LOW NOISE OPERATION IN A COMPACT SIZE
Shorter than the traditional power supply, the RMe offers more cable space behind your PSU.

Includes Zero RPM Fan Mode for near-silent operation at lower loads.

TECHNOLOGY AND RELIABILITY
For consistent, reliable power and superb electrical performance, each RMe Series power supply features a robust resonant LLC topology with DC-DC conversion and 105° rated industrial-grade capacitors.

With precise timings, RMe supports Modern Standby, ensuring extremely fast wake-from-sleep times and better low-load efficiency.

80 PLUS Gold certified
Steady power output at up to 90% efficiency, and Cybenetics-certified for lower power consumption, less noise, and cooler temperatures.

105°C-RATED CAPACITORS
Built with 100% Industrial-grade, 105°C-rated Japanese electrolytic capacitors for unwavering power and reliability.

Power

Total power: 1200 W
AC input voltage: 100 - 240 V
AC input frequency: 47 - 63 Hz
Input current: 15 A
Combined power (+3.3V): 150 W
Combined power (+12V): 1200 W
Combined power (+5V): 150 W
Combined power (+5Vsb): 15 W
Max output current (+3.3V): 20 A
Max output current (+12V): 100 A
Max output current (+5V): 20 A
Max output current (+5Vsb): 3 A

Ports & interfaces

Motherboard power connector: 24-pin ATX
Motherboard power cable length: 61 cm
Number of SATA power connectors: 3
SATA power cable length: 115,455,800 mm
Peripheral (Molex) power connectors (4-pin): 4
Peripheral (Molex) power cable length: 100,450 mm
PCI Express power connectors (6+2 pin): 2
PCI Express power cable length: 60 cm
Number of EPS connectors: 2
Cabling type: Fully-Modular

Performance

80 PLUS certification: 80 PLUS Gold
Purpose: PC
Power supply unit (PSU) form factor: ATX
ATX version: 3.0
Mean time between failures (MTBF): 100000 h

Design

Product colour: Black
Cooling type: Active
Number of fans: 1 fan(s)
Feature: On/off switch

Weight & dimensions

Weight: 3.38 kg
