Zebra CS60-HC

Zebra CS60-HC. Type: Handheld bar code reader, Scanner type: 1D/2D, Sensor type: LED. Connectivity technology: Wireless, Standard interfaces: Bluetooth, USB, Wireless range: 100 m. Product colour: White, International Protection (IP) code: IP65, Certification: FIPS 140-2. Power source type: AC, Battery, DC, USB, Battery type: Built-in battery, Battery life: 18 h. Weight: 87 g, Width: 46 mm, Depth: 109 mm

ULTRA-VERSATILE WITH A FIRST-OF-ITS-KIND CONVERTIBLE DESIGN
The ultra-versatile CS60-HC Healthcare Series Companion Scanner is designed specifically for healthcare and adapts to any clinician workflow. Its groundbreaking design easily converts between corded and cordless operation, handheld and hands-free, as your needs change for superior investment protection. And it features a purpose-built housing that helps offer maximum protection against the spread of bacteria, including a crevice-free surface that helps eliminate places where germs can hide.

ADAPTS TO ANY CLINICIAN WORKFLOW
As a cordless companion scanner, the CS60-HC is small enough to meet any nurse-carry workflow. And as a corded scanner, the CS60-HC provides compact scanning for the pharmacy counter, lab station and more. Whether you purchase a corded or cordless model up front, you can change modes at any time.

CUTTING-EDGE CLINICAL MOBILITY
With Qi inductive charging, split-second NFC tap-to-pair, Bluetooth 5.0 with Wi-Fi friendly mode, an 18-hour battery and Virtual Tether anti-loss functionality, the cordless CS60-HC is pocketable and wearable when clinician mobility is essential.

PURPOSE BUILT FOR HEALTHCARE
Thanks to a safe LED aimer, night mode and an IP65 sealed disinfectant-ready housing with a crevice-free surface that helps eliminate places where germs can hide, the CS60-HC is designed to be used throughout the whole hospital including the NICU, labour and delivery and mother-baby units.

Scanning

Type: Handheld bar code reader
Scanner type: 1D/2D
Sensor type: LED
Linear (1D) barcodes supported: Codabar, Code 11, Code 128, Code 39, Code 93, GS1 DataBar, MSI, Plessey, U.P.C.
2D (matrix & stacked) barcodes supported: Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39
Optical sensor resolution (W x H): 1280 x 960 pixels
Light levels (direct sunlight): 0 - 108000 lx
Wavelength: 525 nm
Tilt reading angle: -60 - 60°
Pitch reading angle: -60 - 60°
Yaw reading angle: 0 - 360°

Ports & interfaces

Connectivity technology: Wireless
Standard interfaces: Bluetooth, USB
Wireless range: 100 m
Bluetooth version: 5.0
Feature: Bluetooth Low Energy (BLE)

Performance

International Protection (IP) code: IP65
LED indicators: Yes
Product colour: White
Certification: FIPS 140-2

Power

Power source type: AC, Battery, DC, USB
Battery type: Built-in battery
Number of reads per charge: 13000
Battery life: 18 h
Charging time: 6 h
Power consumption: 400 mA

Weight & dimensions

Width: 46 mm
Depth: 109 mm
Height: 23 mm
Weight: 87 g
Base weight: 96 g
Base dimensions (WxDxH): 90 x 53 x 61 mm

Packaging data

Feature: Charging base

Operational conditions

Operating temperature (T-T): 0 - 50 °C
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 5 - 95%
Storage relative humidity (H-H): 5 - 95%

Battery

Battery technology: Lithium Polymer (LiPo)
Battery capacity: 735 mAh

Technical details

Compliance certificates: RoHS

Logistics data

Harmonized System (HS) code: 84716070
