DELL Pro Max 14 MC14255

DELL Pro Max 14 MC14255. Product type: Mobile workstation, Form factor: Clamshell. Processor family: AMD Ryzen AI 7 PRO, Processor model: 350, Processor frequency: 2 GHz. Display diagonal: 35.6 cm (14"), HD type: Full HD+, Display resolution: 1920 x 1200 pixels. Internal memory: 32 GB, Internal memory type: LPDDR5x-SDRAM. Total storage capacity: 1 TB, Storage media: SSD. On-board graphics card model: AMD Radeon 860M. Operating system installed: Windows 11 Pro. Product colour: Black

Design

Colour name: Magnetite
Product type: Mobile workstation
Product colour: Black
Form factor: Clamshell

Display

Display diagonal: 35.6 cm (14")
Display resolution: 1920 x 1200 pixels
HD type: Full HD+
Panel type: WVA
Feature: LED backlight
Native aspect ratio: 16:10
Feature: Anti-glare screen
Display brightness: 400 cd/m²
Pixel density: 162 ppi
RGB colour space: NTSC
Colour gamut: 45%
Display response rise/fall: 35 ms
Maximum refresh rate: 60 Hz
Contrast ratio (typical): 800:1

Processor

Processor manufacturer: AMD
Processor family: AMD Ryzen AI 7 PRO
Processor generation: AMD Ryzen AI PRO 300 Series
Processor model: 350
Processor cores: 8
Processor threads: 16
Processor boost frequency: 5 GHz
Processor frequency: 2 GHz
Processor cache type: L2 & L3
L3 cache: 16 MB
L2 cache: 8 MB
Processor base power: 28 W

Neural processor unit (NPU)

Feature: Copilot+ PC
Neural processor unit (NPU): AMD Ryzen AI
Total processor performance up to: 66 TOPs
NPU performance up to: 50 TOPs

Memory

Internal memory: 32 GB
Internal memory type: LPDDR5x-SDRAM
Memory form factor: On-board
Memory layout (slots x size): 1 x 32 GB
Maximum internal memory: 16 GB
Memory channels: Dual-channel
Memory data transfer rate: 8000 MT/s
Feature: Non-ECC

Storage

Total storage capacity: 1 TB
Storage media: SSD
Total SSDs capacity: 1 TB
Number of SSDs installed: 1
SSD capacity: 1 TB
SSD memory type: TLC
SSD interface: PCI Express 4.0
Feature: NVMe
SSD form factor: M.2
Feature: Self-Encrypting Drive (SED)
Optical drive type: No

Graphics

Discrete graphics card model: Not available
Feature: On-board graphics card
On-board GPU manufacturer: AMD
On-board graphics card family: AMD Radeon
On-board graphics card model: AMD Radeon 860M

Audio

Audio chip: Realtek ALC3329
Number of built-in speakers: 2
Speaker power: 2 W
Feature: Built-in microphone
Number of microphones: 2

Camera

Feature: Front camera
Front camera resolution (numeric): 2.07 MP
Front camera resolution: 1920 x 1080 pixels
Front camera HD type: Full HD
Video capturing speed: 30 fps
Feature: Privacy camera
Privacy type: Privacy shutter

Network

Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be)
Wi-Fi band: Tri-band (2.4 GHz / 5 GHz / 6 GHz)
Wi-Fi data rate (max): 2882 Mbit/s
WLAN controller model: MediaTek MT7925
WLAN controller manufacturer: MediaTek
Feature: Ethernet LAN
Ethernet LAN data rates: 10,100,1000 Mbit/s
Feature: Bluetooth
Feature: Near Field Communication (NFC)

Ports & interfaces

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Ethernet LAN (RJ-45) ports: 1
HDMI ports quantity: 1
HDMI version: 2.1
Thunderbolt 4 ports quantity: 2
Feature: Intel® Thunderbolt 4
Feature: Combo headphone/mic port
Feature: USB Type-C DisplayPort Alternate Mode
Feature: PowerShare

Performance

Motherboard chipset: AMD SoC
Feature: Accelerometer
Feature: Hall sensor

Keyboard

Pointing device: Touchpad
Feature: Keyboard backlit
Keyboard language: German
Feature: Copilot key

Software

Operating system architecture: 64-bit
Trial software: Activate Your Microsoft 365 For A 30 Day Trial
Operating system installed: Windows 11 Pro

Brand-specific features

Brand specific technologies: TNR, Express Charge Boost capable, Control Vault 3+

Battery

Battery technology: Lithium Polymer (LiPo)
Number of battery cells: 4
Battery capacity: 72 Wh
Battery voltage: 15.6 V
Battery recharge time: 3 h
Feature: Fast charging

Power

Feature: USB Type-C charging port
USB Type-C required charging power (min): 45 W
USB Type-C required charging power (max): 100 W
Feature: USB Power Delivery (USB PD)

Security

Feature: Cable lock slot
Cable lock slot type: Wedge
Feature: Fingerprint reader
Feature: Trusted Platform Module (TPM)
Trusted Platform Module (TPM) version: 2.0

Operational conditions

Operating temperature (T-T): 0 - 35 °C
Storage temperature (T-T): -40 - 65 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 0 - 95%
Operating altitude: -15.2 - 3048 m
Non-operating altitude: -15.2 - 10668 m
Operating shock: 110 G
Non-operating shock: 160 G
Operating vibration: 0.66 G
Non-operating vibration: 1.3 G

Weight & dimensions

Width: 313 mm
Depth: 227.3 mm
Height (front): 1.48 cm
Height (rear): 1.89 cm
Weight: 1.79 kg

Carbon footprint

Total carbon footprint (kg of CO2e): 105
Carbon emissions, manufacturing (kg of CO2e): 79.7
Carbon emissions, logistics (kg of CO2e): 3.36
Carbon emissions, energy usage (kg of CO2e): 21.53
Carbon emissions, end-of-life (kg of CO2e): 0.42
PAIA version: GaBi version 1, 2025
