DELL Latitude 7530

DELL Latitude 7530. Product type: Laptop, Form factor: Clamshell. Processor family: Intel® Core™ i5, Processor model: i5-1245U. Display diagonal: 39.6 cm (15.6"), HD type: Full HD, Display resolution: 1920 x 1080 pixels. Internal memory: 16 GB, Internal memory type: DDR4-SDRAM. Total storage capacity: 256 GB, Storage media: SSD. On-board graphics card model: Intel Iris Xe Graphics. Operating system installed: Windows 10 Pro. Product colour: Black. Weight: 1.54 kg

Design

Product type: Laptop
Product colour: Black
Form factor: Clamshell
Market positioning: Premium
Introduction year: 2022
Feature: Intel® vPro™ Platform Eligibility

Display

Display diagonal: 39.6 cm (15.6")
Display resolution: 1920 x 1080 pixels
HD type: Full HD
Panel type: WVA
Feature: LED backlight
Native aspect ratio: 16:9
Feature: Anti-glare screen
Display brightness: 250 cd/m²
Pixel pitch: 0.17925 x 0.17925 mm
Pixel density: 141 ppi
RGB colour space: NTSC
Colour gamut: 45%
Display response rise/fall: 25 ms
Maximum refresh rate: 60 Hz
Contrast ratio (typical): 700:1

Processor

Processor manufacturer: Intel
Processor family: Intel® Core™ i5
Processor generation: 12th gen Intel® Core™ i5
Processor model: i5-1245U
Processor cores: 10
Processor threads: 12
Processor boost frequency: 4.4 GHz
Processor cache: 12 MB
Configurable TDP-down: 12 W

Memory

Internal memory: 16 GB
Internal memory type: DDR4-SDRAM
Memory clock speed: 3200 MHz
Memory form factor: On-board
Maximum internal memory: 16 GB

Storage

Total storage capacity: 256 GB
Storage media: SSD
Total SSDs capacity: 256 GB
Number of SSDs installed: 1
SSD capacity: 256 GB
SSD interface: NVMe, PCI Express
Feature: NVMe
SSD form factor: M.2
SSD performance class: 35
Optical drive type: No

Graphics

Discrete graphics card model: Not available
Feature: On-board graphics card
On-board GPU manufacturer: Intel
On-board graphics card model: Intel Iris Xe Graphics

Audio

Audio chip: Realtek ALC3281-CG
Audio system: MaxxAudio Pro
Number of built-in speakers: 2
Speaker power: 2 W
Feature: Built-in microphone
Number of microphones: 2

Camera

Feature: Front camera
Front camera resolution (numeric): 2 MP
Front camera resolution: 1920 x 1080 pixels
Front camera HD type: Full HD
Video capturing speed: 30 fps
Feature: Infrared (IR) camera

Network

Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6E (802.11ax)
Wi-Fi data rate (max): 2400 Mbit/s
Antenna type: 2x2
WLAN controller model: Intel Wi-Fi 6E AX211
WLAN controller manufacturer: Intel
Feature: Bluetooth
Feature: Near Field Communication (NFC)
WWAN: Installed

Ports & interfaces

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
HDMI ports quantity: 1
HDMI version: 2.0
Thunderbolt 4 ports quantity: 2
Feature: Intel® Thunderbolt 4
Feature: Combo headphone/mic port
Feature: USB Type-C DisplayPort Alternate Mode
Feature: PowerShare
Number of USB ports with PowerShare support: 2

Keyboard

Pointing device: Touchpad
Feature: Keyboard backlit
Keyboard language: German

Software

Operating system architecture: 64-bit
Operating system language: German, Dutch, English, French, Italian
Feature: Windows 11 free upgrade
Trial software: No Microsoft Office License Included 30 day Trial Offer Only
Operating system installed: Windows 10 Pro

Processor special features

Feature: Intel Flex Memory Access
Feature: Intel Trusted Execution Technology
Feature: Intel VT-x with Extended Page Tables (EPT)
Feature: Intel Stable Image Platform Program (SIPP)
Feature: Execute Disable Bit
CPU configuration (max): 1
Feature: Intel Virtualization Technology for Directed I/O (VT-d)
Feature: Intel Virtualization Technology (VT-x)

Battery

Battery technology: Lithium-Ion (Li-Ion)
Number of battery cells: 4
Battery capacity: 58 Wh
Battery voltage: 15.2 V
Battery recharge time: 3 h
Feature: Fast charging
Battery weight: 240 g

Power

AC adapter power: 65 W
AC adapter frequency: 50/60 Hz
AC adapter input voltage: 100 - 240 V
Feature: USB Type-C charging port
Feature: USB Power Delivery (USB PD)
USB charging voltage: 20,5,9,15 V
USB charging current: 3.25 A

Security

Feature: Cable lock slot
Feature: Fingerprint reader
Feature: Smart card reader
Feature: Trusted Platform Module (TPM)
Trusted Platform Module (TPM) version: 2.0
Feature: Password protection

Operational conditions

Operating temperature (T-T): 0 - 35 °C
Storage temperature (T-T): -40 - 65 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 0 - 95%
Operating altitude: -15.2 - 3048 m
Non-operating altitude: -15.2 - 10668 m
Operating shock: 110 G
Non-operating shock: 160 G
Operating vibration: 0.66 G
Non-operating vibration: 1.3 G

Sustainability

Sustainability certificates: ENERGY STAR, EPEAT Gold

Weight & dimensions

Width: 357.7 mm
Depth: 229.8 mm
Height (front): 1.77 cm
Height (rear): 1.89 cm
Weight: 1.54 kg

Packaging content

Cables included: AC
