TP-LINK Omada kelių gigabitų VPN maršrutizatorius
Prekės kodas: 18-ER7412-M2

TP-LINK Omada kelių gigabitų VPN maršrutizatorius


TP-LINK Omada kelių gigabitų VPN maršrutizatorius
TP-LINK Omada kelių gigabitų VPN maršrutizatorius
TP-LINK Omada kelių gigabitų VPN maršrutizatorius
TP-LINK Omada kelių gigabitų VPN maršrutizatorius
TP-LINK Omada kelių gigabitų VPN maršrutizatorius
TP-LINK Omada kelių gigabitų VPN maršrutizatorius

TP-LINK Omada kelių gigabitų VPN maršrutizatorius

Prekės kodas: 18-ER7412-M2

TP-LINK Omada kelių gigabitų VPN maršrutizatorius


Jūsų palyginimo sąraše yra 3 prekės, prašome vieną pašalinti ir bandyti dar kartą.
  • Įtraukti į patikusias prekes
  • Pridėta į patikusias prekes
  • Pašalinta iš patikusų prekių
Įtraukti į palyginimą
222,43 €
Paskutinė prekė

Garantija
12 mėn.

Pristatymas iš Lietuvos
per 2 - 4*
d. d.

Jūsų žinutė sėkmingai išsiųsta!
Užpildykite privalomus laukus*

  • Quad-core @2.0GHz CPU

  • 2× 2.5G RJ45 WAN/LAN ports

  • 10× Gigabit WAN/LAN Ports (2× SFP, 8× RJ45)

  • 1× USB 3.0 Port (Supports USB storage, and LTE backup with LTE dongle)

  • Load Balancing on up to 11 WAN ports increases the utilization rate of multi-line broadband

  • High-security SSL/ IPSec / GRE / WireGuard / PPTP / L2TP VPN OpenVPN

  • Centralized cloud management via the web or the Omada app

  • DoS/DDoS protection, IP/MAC/URL filtering, DPI, and IPS/IDS for enhanced security


























SECURITY
Access Control• Source/Destination IP-Based ACL

• Stateful ACL

• IPv4/IPv6 ACL

• Location Based ACL
Filtering• WEB Group Filtering§

• URL Filtering

• Web Security
ARP Inspection• Sending GARP Packets§

• ARP Scanning§

• IP-MAC Binding§
Attack Defense• TCP/UDP/ICMP Flood Defense

• Block TCP Scan (Stealth FIN/Xmas/Null)

• Block Ping from WAN

























































HARDWARE FEATURES
Standards and Protocols• IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE802.1q

• TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, OpenVPN, WireGuard VPN, GRE VPN, SNMP
Interface• 1× 2.5G RJ45 WAN/LAN Port

• 1× 2.5G RJ45 WAN/LAN Port

• 2× Gigabit SFP WAN/LAN Ports

• 8× Gigabit RJ45 WAN/LAN Ports



• 1× RJ45 Console Port

• 1× USB 3.0 Port (Supports USB storage, and LTE backup with LTE dongle)
Network Media• 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m)

• 100BASE-TX: UTP category 5, 5e cable (Max 100 m) EIA/TIA-568 100Ω STP (Max 100 m)

• 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100 m)

• 2500BASE-T: UTP category 5e, 6 cable (Max 100 m)
ButtonReset Button
Power Supply100-240 VAC, 50/60 Hz
Flash128MB NAND
DRAM1 GB DDR4
Dimensions ( W x D x H )11.6×7.1×1.7 in (294×180×44 mm)
Protection4 kV surge protection
EnclosureSteel
Mounting• Desktop

• Rackmountable
Max Power Consumption18.5W (With USB 3.0 connected)









































































PERFORMANCE
GRE• Unencrypted: 1153.0 Mbps

• Encrypted: 559.2 Mbps
WireGuard VPN771.6 Mbps
Concurrent Session1,000,000
New Sessions /Second7,000
NAT (Static IP)2345.71 Mbps / 2351.22 Mbps
NAT(DHCP)2353.41 Mbps / 2353.40 Mbps
NAT(PPPoE)2336.52 Mbps / 2336.08 Mbps
NAT (L2TP)1937.53 Mbps / 1761.82 Mbps
NAT (PPTP)1757.54 Mbps / 2011.33 Mbps
IPsec VPN Throughput• ESP-SHA1-AES256: 1125.60 Mbps

• ESP-SHA256-AES256: 1133.1 Mbps

• ESP-SHA384-AES256: 1126.6 Mbps

• ESP-SHA512-AES256: 1132.8 Mbps
OpenVPNUDP: 266.2 Mbps
L2TP VPN Throughput• Unencrypted: 2724.5 Mbps

• Encrypted: 1018.4Mbps
PPTP VPN Throughput• Unencrypted: 3035 Mbps

• Encrypted: 534.6 Mbps
SSL VPN Throughput263.1 Mbps
66 Byte Packet forwarding rate1833 Mbps / 1835 Mbps
1,518 Byte Packet forwarding rate2461 Mbps / 2461 Mbps

































BASIC FUNCTIONS
WAN Connection Type• Static IP/Dynamic IP

• PPPoE (supports MRU Configuration)

• PPTP

• L2TP

• Mobile Broadband: 4G/3G modem for backup via USB port
MAC CloneModify WAN/LAN MAC Address
DHCP• DHCP Server

• DHCPv6 PD Server (only in Standalone Mode)

• DHCP Options Customization

• DHCP Address Reservation

• Multi-IP Interfaces

• Multi-Net DHCP
IPv6StaticIP / SLAAC / DHCPv6 / PPPoE / 6to4Tunnel / PassThrough / Non-Address mode
VLAN802.1Q VLAN
IPTVIGMP v2/v3 Proxy, Custom Mode, Bridge Mode





























ADVANCED FUNCTIONS
Advanced Routing• Static Routing

• Policy Routing

• RIP (available in Standalone Mode)

• OSPF (available in Standalone Mode)
Bandwidth ControlIP/Port-based Bandwidth Control
Load Balance• Intelligent Load Balance

• Application Optimized Routing

• Link Backup (Timing§, Failover)

• Online Detection
NAT• One-to-One NAT

• Multi-Net NAT

• Virtual Server

• Port Triggering

• NAT-DMZ

• FTP/H.323/SIP/IPSec/PPTP ALG

• UPnP
Session LimitIP-based Session Limit

































VPN
GREOnly in Standalone Mode
SSL VPN80 Tunnels
IPsec VPN• 150 IPSec VPN Tunnels

• LAN-to-LAN, Client-to-LAN

• Main, Aggressive Negotiation Mode

• DES, 3DES, AES128, AES192, AES256 Encryption Algorithm

• IPsec Failover

• IKE v1/v2

• MD5, SHA1, SHA2-384 and SHA2-512 Authentication Algorithm

• NAT Traversal (NAT-T)

• Dead Peer Detection (DPD)

• Perfect Forward Secrecy (PFS)
PPTP VPN• PPTP VPN Server

• PPTP VPN Client (15)

• 150 Tunnels

• PPTP with MPPE Encryption
L2TP VPN• L2TP VPN Server

• L2TP VPN Client (15)

• 150 Tunnels

• L2TP over IPSec
OpenVPN• OpenVPN Server

• OpenVPN Client (11)

• 121 OpenVPN Tunnels

• 'Certificate + Account' Mode

• Full Mode













AUTHENTICATION
Web Authentication• No Authentication

• Simple Password

• Hotspot (Local User/Voucher/SMS/Radius)

• External Radius Server

• External Portal Server

• LDAP





































MANAGEMENT
Omada AppYes. Requiring the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
Centralized Management• Omada Cloud-Based Controller

• Omada Hardware Controller

• Omada Software Controller
Cloud AccessYes. Requiring the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
ServiceDynamic DNS (Dyndns, No-IP, Peanuthull, Comexe, DDNS Customization)
Maintenance• Web Management Interface

• Remote Management

• Export Import Configuration

• SNMP v1/v2c/v3

• Diagnostics (Ping Traceroute)

• NTP Synchronize

• Port Mirroring

• CLI (only in Standalone Mode)

• Syslog Support
Zero-Touch ProvisioningYes. Requiring the use of Omada Cloud-Based Controller.
Management Features• Automatic Device Discovery

• Batch Configuration

• Batch Firmware Upgrading

• Intelligent Network Monitoring

• Abnormal Event Warnings

• Unified Configuration

• Reboot Schedule

























OTHERS
CertificationCE, FCC
Package Contents• ER7412-M2

• Power Cord

• Quick Installation Guide

• Rackmount Kit

• RJ45 Console Cord
System Requirements• Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10/11

• MAC OS, NetWare, UNIX or Linux
Environment• Operating Temperature: 0-45 (32-113 )

• Storage Temperature: -40-70 (-40-158 )

• Operating Humidity: 10-90% RH non-condensing

• Storage Humidity: 5-90% non-condensing
