„StarTech.com“ SV565HDIP KVM komutatorius

StarTech.com HDMI KVM Extender over IP Network - 4K 30Hz HDMI 2.0 and USB over IP LAN or Cat5e/Cat6 Ethernet Cable (100m/330ft) - Remote KVM Switch/Console Transmitter/Receiver Extender Kit - TAA. Keyboard port type: USB, Mouse port type: USB, Video port type: HDMI. HD type: 4K Ultra HD, Maximum resolution: 3840 x 2160 pixels, Video bandwidth: 30 Hz. Product colour: Black, Housing material: Steel, Mean time between failures (MTBF): 60000 h. Input voltage: 100 - 240 V, Input current: 0.6 A, Output voltage: 12 V. Compliance certificates: RoHS

KVM Console Extender Over IP | HDMI® | 4K @ 30Hz | 4x USB Ports | EDID Pass-Through

This HDMI KVM extender kit lets you use a keyboard, mouse and monitor to remotely control any computer over your IP-enabled local area network (LAN). Combined with a KVM switch, the KVM console extender can be used with multiple computers. The extender features four USB ports that enable you to connect other USB devices, in addition to your keyboard and mouse.

Supports UHD 4K 30Hz

The HDMI KVM extender delivers astonishing 4K UHD picture quality to your remote display with support for resolutions up to 3840 x 2160p at 30Hz.

Hassle-Free Installation

With a transmitter and a receiver, the KVM extender provides a complete end-to-end solution that supports mounting for tidy installation. Plus, it uses standard CAT5e or CAT6 Ethernet cable, eliminating the expense and hassle of specialized cables and enabling you to use existing network infrastructure.

The extender supports EDID pass-through, ensuring your computer can automatically configure optimal settings for your display over your LAN.

Versatile Configuration Options

The extender uses your local intranet to connect your computers to your remote workstation. You can connect additional receivers (sold separately) to distribute your HDMI signal to multiple displays in your remote location, or combine the source to create a video wall that expands your single video source across multiple displays.

For smaller-scale applications, you can connect the transmitter and receiver units directly over CAT5e or CAT6 cabling up to 330 feet (100 meters).

SV565HDIP is backed by a 2-year warranty and free lifetime technical support.

Ports & interfaces

Keyboard port type: USB
Mouse port type: USB
Video port type: HDMI
HDMI ports quantity: 2
Feature: USB hub
USB 2.0 Type-A hub ports quantity: 2
Feature: Audio connections
Headphone outputs: 8
Number of microphone inputs: 2
Feature: DC-in jack

Network

Ethernet LAN (RJ-45) ports: 2

Performance

HD type: 4K Ultra HD
Maximum resolution: 3840 x 2160 pixels
Video bandwidth: 30 Hz
Maximum operating distance: 100 m
Chipset: ASPEED - AST1520
Audio channels: 7.1

Design

Product colour: Black
Housing material: Steel
LED indicators: Yes
Mean time between failures (MTBF): 60000 h
Certification: CE, FCC, TAA, REACH

Display

Feature: On Screen Display (OSD)

Power

Input voltage: 100 - 240 V
Input current: 0.6 A
Output voltage: 12 V
Output current: 1.5 A
Power consumption (typical): 18 W
Feature: External power adapter
Power plug type: Type M
Compatible power plug types: AU, EU, JP, UK

Sustainability

Compliance certificates: RoHS

Operational conditions

Operating temperature (T-T): 0 - 40 °C
Storage temperature (T-T): -10 - 60 °C
Operating relative humidity (H-H): 0 - 80%

Weight & dimensions

Width: 117 mm
Depth: 130 mm
Height: 28 mm
Weight: 610 g

Packaging data

Package width: 354 mm
Package depth: 368 mm
Package height: 80 mm

Packaging content

Cables included: HDMI, LAN (RJ-45), Phone (RJ-11), USB
Feature: Quick installation guide
Feature: AC adapter included
Feature: Rubber feet

Logistics data

Harmonized System (HS) code: 85176200
Master (outer) case width: 394 mm
Master (outer) case length: 490 mm
Master (outer) case height: 272 mm
Products per master (outer) case: 6 pc(s)
