„Broadcom HBA 9500-8i“ sąsajos plokštės / adapteris

Broadcom HBA 9500-8i. Host interface: PCIe, Output interface: SAS, SATA, Expansion card form factor: Full-height / Low-profile. Product colour: Green, Grey, Mean time between failures (MTBF): 5000000 h, Certification: Australia/New Zealand (AS/NZS CISPR 22), Canada ICES-003 Class B, CE Europe (EN55022/EN55024),.... Data transfer rate (max): 12 Gbit/s. Power consumption (typical): 5.96 W. Width: 155 mm, Depth: 68 mm

PCIe Gen 4.0 HBA provides high bandwidth and unprecedented flexibility to today's expanding data centers with Tri-Mode connectivity and NVMe devices
The 9500-8i Tri-Mode, PCIe Gen 4.0 HBA with eight internal ports is ideal for increased connectivity and maximum performance for enterprise data center flexibility.

With increased bandwidth and IOPS performance compared to previous generations, the 9500-8i adapter delivers the performance and scalability needed by critical applications.

Ports & interfaces

Host interface: PCIe
Output interface: SAS, SATA
Expansion card form factor: Full-height / Low-profile
Feature: NVMe

Design

Feature: Internal
Product colour: Green, Grey
Mean time between failures (MTBF): 5000000 h

Features

Data transfer rate (max): 12 Gbit/s
Feature: Plug and Play

Power

Power consumption (typical): 5.96 W

Operational conditions

Operating temperature (T-T): 0 - 50 °C
Operating relative humidity (H-H): 20 - 80%

System requirements

Windows operating systems supported: Yes
Linux operating systems supported: Yes
Other operating systems supported: Yes

Technical details

Compliance certificates: RoHS

Weight & dimensions

Width: 155 mm
Depth: 68 mm

Packaging data

Quantity: 1

Logistics data

Harmonized System (HS) code: 84733020
