ALLNET ALL3692 optinis galios matuoklis

ALLNET ALL3692. Certification: CE, RoHS. Width: 155 mm, Depth: 28 mm, Height: 26 mm

The Allnet ALL3692 is the consistent further development of the successful ALL369x Power Meter series, this time for D0 power meter with optical output. This concrete and calibrated readings are always recognized.

- Instrument for monitoring and control of your current power consumption at several measuring points
- Via the Internet from anywhere accessible (Internet connection at the location of ALL3692 required)
- Easy operation and installation through Web interface and the D0 OKK optical read head ALL3688, alternatively ALL3689 (no interference with the house wiring necessary)
- integrated web server
- Email alerting at a set value is exceeded
- 4 x D0 ports allows you to connect with each D0 power meter with optical output (ALL3688/ALL3689)
- Extensive consumption display with live chart, chart function, table display, etc.
- Possibility to download the readings in database format, eg as a CSV file
- Interfaces: 1 x network, 1x 300Mbit Wireless, D0 4x, 2x I2C sensor / port, 2x External USB ports

Features

Certification: CE, RoHS

Operational conditions

Operating temperature (T-T): 5 - 40 °C
Storage temperature (T-T): -20 - 60 °C
Operating relative humidity (H-H): 10 - 85%
Storage relative humidity (H-H): 5 - 95%

Weight & dimensions

Width: 155 mm
Depth: 28 mm
Height: 26 mm
Weight: 260 g

Packaging content

Feature: Manual
Feature: AC adapter included
