EXTRALINK 16 branduolių šviesolaidinio skirstomoji dėžutė ELENA

This lockable distribution box offers the ability to terminate 16 fibres housed in a strong robust SMC enclosure for indor and outdoor application.

With the ability to us both SC simplex and LC duplex adapter type soffering a flexible solution to the end user, enabling them to incorporate a multi-functional enclosure which allows easy access during installation or re-work with no disturbance of the existing cable or fibres.

In addition to the interchangeable adaptors the enclosure also offers up to tube, tight buffer, pre-terminated and steel tape armoured cable.

Each enclosure has integrated strength member tie positions and bend radius protection with the addition of a removable from door allowing for quick and easy installation.

Features:
• Up to 16 fibres;
• Removable splice tray for easy installation;
• Multiple adapter options available;
• Accepts loose tube, distribution and pre-terminated cables;
• Integrated bend radius protection;
• Removable door for ease of installation;
• Supplied with 16 heat shrink splice protectors;
• Supplied with transit tubing;
• Supplied with wall fixings and tie wrap.

Application:
• Data centres, premise installations, telecommunication networks;
• Ethernet, fibre Channel, ATM, LAN, MAN and WAN;
• Data communication and telecommunication networks;
• Wall mounted/pole mounted, Indoor/outdoor applications.

• Dimensions: 315*235*100mm;
• Capacity: 16 Fibers;
• Adapters: 16*SC Simplex, 16*LC Duplex(not included);
• Operation Temperature: -40°C~+60°C;
• Net Weight: 1.25kg;
• GrossWeight: 1.35kg;
• Colour: White.
