Network Equipment - TP-Link Omada MC211CS-20 Media Converter 1000Mbit/s SC/UPC
Product reference:
14-1210002601085
TP-Link Omada MC211CS-20 is a single-mode fiber media converter that supports data transfer rates up to 1000 Mbit/s over distances up to 20,000 meters. It features one fiber port with SC/UPC connector and one Ethernet LAN (RJ-45) port.
Network Equipment - TP-Link Omada MC211CS-20 Media Converter 1000Mbit/s SC/UPC
Product reference:
14-1210002601085
TP-Link Omada MC211CS-20 is a single-mode fiber media converter that supports data transfer rates up to 1000 Mbit/s over distances up to 20,000 meters. It features one fiber port with SC/UPC connector and one Ethernet LAN (RJ-45) port.
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
15 - 16
business days
TP-Link Omada MC211CS-20 Network Media Converter 1000 Mbit/s 1310 Nm Single Mode Black
TP-Link Omada MC211CS-20 is a single-mode fiber media converter that supports data transfer rates up to 1000 Mbit/s over distances up to 20,000 meters. It features one fiber port with SC/UPC connector and one Ethernet LAN (RJ-45) connector.
- High data transfer speed up to 1000 Mbit/s for efficient network operation.
- Supports long-distance communications with a maximum transmission distance of up to 20,000 meters.
- Single-mode fiber technology with 1310 nm wavelength for optimal signal quality.
- Easy installation with auto MDI/MDI-X support for seamless connectivity.
Features | |
|---|---|
| Product Type | Media Converter |
| Product Brand | TP-Link |
| Model | Omada MC211CS-20 |
Specifications | |
| Dimensions | 94.5 mm × 27 mm × 73 mm (W × H × D) |
| Weight | Not specified |
| Color | Black |
Technical Data | |
| Input Voltage | 9 V |
| Input Current | 0.6A |
| Operating Temperature | -5°C to 50°C |
| Storage Temperature | -40°C to 70°C |
| Operating Humidity | 10% to 90% |
| Storage Humidity | 5% to 90% |
Network | |
| Maximum Data Transfer Rate | 1000 Mbps |
| Duplex System | Half, Full |
| Network Standards | IEEE 802.3x, IEEE 802.3z, IEEE 802.3i, IEEE 802.3u, IEEE 802.3, IEEE 802.3ab |
| Auto MDI/MDI-X | Yes |
Operation | |
| Wavelength | 1310 nm |
| Maximum Transmission Distance | 20,000 m |
| Fiber Mod Structure | Single mode |
Connectors Interfaces | |
| Fiber Connector Quantity | 1 |
| Ethernet LAN (RJ-45) Connectors | 1 |
| Fiber Optic Connector | SC/UPC |
Security Warning | |
| Use the product for its intended purpose to ensure safety and performance. | |
