Motherboard - ASUS TUF GAMING B850M-PLUS WIFI AMD B850 Socket AM5 Micro ATX
Product reference:
14-4711387764916
Supports AMD Ryzen 7000, 8000, and 9000 series processors with AM5 socket. The device features Wi-Fi 6E, 4 memory slots supporting up to 192GB DDR5, and a wide range of I/O ports including USB 3.2 and HDMI.
Motherboard - ASUS TUF GAMING B850M-PLUS WIFI AMD B850 Socket AM5 Micro ATX
Product reference:
14-4711387764916
Supports AMD Ryzen 7000, 8000, and 9000 series processors with AM5 socket. The device features Wi-Fi 6E, 4 memory slots supporting up to 192GB DDR5, and a wide range of I/O ports including USB 3.2 and HDMI.
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
24 month
Delivery from Europe in
8 - 9
business days
ASUS TUF Gaming B850M-Plus WiFi AMD B850 Socket AM5 Micro ATX
Compatible with AMD Ryzen 7000, 8000, and 9000 series processors with Socket AM5. Features Wi-Fi 6E, 4 memory slots supporting up to 192GB DDR5, and a wide range of I/O ports including USB 3.2 and HDMI.
- Compatible with AMD Ryzen 7000, 8000 and 9000 series processors (Socket AM5)
- Facilitates the use of up to 192 GB of DDR5-SDRAM memory via 4 DIMM slots
- Integrated Wi-Fi 6E (802.11ax) and Bluetooth 5.3 for better connectivity
- Features 7.1 channel audio output with Realtek ALC1220P audio chip
- Multiple expansion slots included: 1 x PCIe x16 (Gen 5.x), 1 x PCIe x1 (Gen 4.x), and 3 M.2 slots
Processor | |
|---|---|
| Compatible processor series | AMD Ryzen 7000, 8000, 9000 series |
| Processor sockets are made easier | Socket AM5 |
| Processor manufacturer | AMD |
Graphics | |
| Support for parallel processing technology | Not supported |
Features | |
| Audio output channels | 7.1 channels |
| Supported Windows operating systems | Windows 10 x64, Windows 11 |
| Motherboard format type | micro ATX |
| Audio chip | Realtek ALC1220P |
| Motherboard chipset family | AMD |
| Motherboard chip | AMD B850 |
Memory | |
| Unbuffered memory | Yes |
| Number of memory slots | 4 |
| Maximum internal memory | 192GB |
| Memory channels | Dual channel |
| Supported memory types | DDR5-SDRAM |
| Memory slot type | DIMMs |
| ECC compatibility | ECC Non-ECC |
Weight and dimensions | |
| Depth | 244 mm |
| Width | 244 mm |
Network | |
| Wi-Fi standards | Wi-Fi 6E (802.11ax) |
| Ethernet LAN | Yes |
| Bluetooth version | 5.3 |
Internal I/O | |
| USB 3.2 Gen 2 ports | 1 |
| Number of chassis fan connectors | 3 |
| 12V power connector | Yes |
| USB 2.0 ports | 2 |
| Number of SATA III connectors | 4 |
BIOS | |
| BIOS type | UEFI AMI |
Packaging details | |
| Package height | 67.5 mm |
| Package width | 275 mm |
| Package weight | 1.68 kg |
| Package depth | 275 mm |
Memory controllers | |
| RAID support | Yes |
| Supported storage device types | HDD SSD |
| Number of supported storage devices | 7 |
Rear panel I/O connectors | |
| USB 3.2 Gen 2x2 Type-C connectors | 1 |
| USB 2.0 ports | 4 |
| HDMI connections | 1 |
| Ethernet LAN (RJ-45) connectors | 1 |
Expansion slots | |
| PCI Express x16 (Gen 5.x) slots | 1 |
| Number of M.2 slots | 3 |
Other features | |
| Weight | 1.2 kg |
