Motherboard - ASUS TUF GAMING B650M-E WIFI AM5 micro ATX
Product reference:
14-4711387222041
Supports AMD Ryzen 7000 series processors with AM5 socket and has four DDR5 memory slots for up to 128GB of memory. The device features Wi-Fi 6, Bluetooth 5.2, and multiple USB ports for convenient connectivity.
Motherboard - ASUS TUF GAMING B650M-E WIFI AM5 micro ATX
Product reference:
14-4711387222041
Supports AMD Ryzen 7000 series processors with AM5 socket and has four DDR5 memory slots for up to 128GB of memory. The device features Wi-Fi 6, Bluetooth 5.2, and multiple USB ports for convenient connectivity.
You have 3 products in compare list, please remove someone and try again
- Add to favorites products
- Added to favorites products
- Removed to favorites product
Guarantee
12 month
Delivery from Europe in
8 - 9
business days
ASUS TUF Gaming B650M-E WIFI AMD B650 Socket AM5 Micro ATX
Compatible with AMD Ryzen 7000 series processors, featuring Socket AM5, and offering four DDR5 memory slots supporting up to 128 GB. Equipped with Wi-Fi 6, Bluetooth 5.2, and multiple USB ports for connectivity.
- Compatible with AMD Ryzen 7000 series processors with Socket AM5 for increased performance.
- Equipped with Wi-Fi 6 and Bluetooth 5.2, ensuring fast and reliable wireless connectivity.
- Featuring 4 DIMM slots for DDR5 memory supporting up to 128 GB, it is designed for fast multitasking.
- Micro ATX form factor board with multiple I/O ports, including USB 3.2 and HDMI, providing a variety of connectivity options.
Processor | |
|---|---|
| Composite processor types | AMD Ryzen 7000 series |
| Processor socket | Socket AM5 |
| Processor manufacturer | AMD |
Features | |
| Supported Windows operating systems | Windows 10 x64, Windows 11 |
| Motherboard format | micro ATX |
| Motherboard chipset | AMD |
| Motherboard chipset | AMD B650 |
| Audio output channels | 7.1 channels |
Memory | |
| Supported memory types | DDR5-SDRAM |
| Number of memory slots | 4 |
| Memory slot type | DIMMs |
| ECC compatibility | ECC Non-ECC |
| Memory channels | Dual channels |
| Supported memory frequencies | 5600, 5800, 5400, 5200, 5000, 6000, 6400, 6200, 4800 |
| Unbuffered memory | Yes |
| Maximum internal memory | 128GB |
Weight and dimensions | |
| Width | 244 mm |
| Height | 50mm |
| Depth | 244 mm |
Network | |
| Ethernet interface type | 2.5 Gigabit Ethernet, Gigabit Ethernet |
| Ethernet LAN | Yes |
| Wi-Fi | Yes |
| Bluetooth version | 5.2 |
| Wi-Fi standards | Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), 802.11g, 802.11b, 802.11a, Wi-Fi 6 (802.11ax) |
| Top Wi-Fi standard | Wi-Fi 6 (802.11ax) |
| Bluetooth | Yes |
Internal I/O | |
| 12V power connector | Yes |
| RGB LED pin header | Yes |
| Number of SATA III connectors | 4 |
| Front panel audio connector | Yes |
| EPS power connector (8-pin) | Yes |
| ATX power connector (24-pin) | Yes |
| Number of USB 3.2 Gen 1 (3.1 Gen 1) ports | 2 |
| CPU cooler connector | Yes |
| Number of chassis cooler connectors | 2 |
| Number of USB 2.0 ports | 2 |
BIOS | |
| BIOS type | UEFI AMI |
Packaging details | |
| Package weight | 1.7 kg |
| Package width | 275 mm |
| Package depth | 275 mm |
| Package height | 67.4 mm |
Memory controllers | |
| Number of supported storage devices | 6 |
| Number of HDDs supported | 4 |
| RAID levels | 1, 10, 0 |
| RAID support | Yes |
| Supported storage device types | HDD SSD |
| Supported memory device interfaces | M.2, SATA III |
Rear panel I/O ports | |
| Microphone input | Yes |
| DisplayPort quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Number of HDMI ports | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| Number of USB 2.0 ports | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| Number of PS/2 ports | 1 |
Expansion slots | |
| Number of M.2 (M) slots | 2 |
| Number of PCI Express x1 (Gen 4.x) slots | 2 |
Other features | |
| Weight | 1.01 kg |
