Lian Li Uni Fan TL LCD

Lian Li Uni Fan TL LCD. Type: Fan, Fan diameter: 14 cm, Rotational speed (min): 400 RPM, Rotational speed (max): 1600 RPM, Maximum air pressure: 3.5 mmH2O, Bearing type: Fluid Dynamic Bearing (FDB). Voltage: 12 V. Width: 144 mm, Depth: 140 mm, Height: 28 mm. Product colour: Black

AVAILABLE IN TWO COLORS/ TWO SIZES/ TWO ORIENTATIONS
Elevate your PC setup with UNI FAN TL LCD black and white fans, available in 120mm and 140mm sizes with normal and reverse blades.

EMPOWER WITH CUSTOMIZABLE DISPLAY
The world's 1st PC case fan with a LCD screen, which can be personalized and controlled using L-Connect 3.

PERFORMANCE DETAIL AT A GLANCE
Monitor the temperature and loading of your CPU and GPU, as well as the fan speed, instantly with built-in hardware monitor dashboards on the screen.

UNIQUE STYLE
Elevate your system's style by uploading your own personalized MP4 / GIF / JPG / PNG.

NEXT GENERATION OF UNI FAN
Building on the design success of the UNI FAN series interlocking system, the UNI FAN TL series takes clutter-free setups to the next level.

Durable Daisy-Chain Solution

Experience a hassle-free setup with the slide-in daisy-chaining mechanism, securely holding the fans in place and ensuring a snug fit for easy configuration.

Seamless Connection

A single cable can connect a group of up to 3 TL LCD fans to a port on the controller, which supports a maximum of 9 TL LCD fans per controller (up to 16 TL+TL LCD fans in total).

L-Connect 3 supports a maximum of 12 TL LCD fans, with an option to add a second controller if needed.

Well-Adapted for all Configurations

The interlocking key at the end of TL LCD fans is removable for enhanced compatibility and less interference with other components.

STABLE OPERATION
UNI FAN TL LCD is engineered for stable fan blade operation, ensuring efficiency at a low noise level.

BREEZE YOUR SYSTEM
Redefining PC cooling experience with a fan that doesn't compromise on thermal control, all while offering a personalized screen for a touch of individuality.

CUSTOMISABLE FAN SPEED
Able to set different fan speeds for each fan cluster to optimize different scenarios of use providing flexibility for radiator or case fan needs with L-Connect 3.

SOPHISTICATED CONTINUOUS RGB LIGHTING
Each UNI FAN TL fan has 26 LEDs with an elegant side diffuser on the 2 sides of the fan frame that wraps around the edges of the anti-vibration pad.

DAZZLE WITH INFINITY MIRROR
Illuminate your setup with the UNI FAN TL's enlarged infinity mirror (30% larger than UNI FAN SL-INF on the side) on both sides of the frame, showcasing clear and 0.7mm gap multi-layer lighting effects.

INDIVIDUAL LIGHTING EFFECTS
Easily customize different lighting effects on the two sides of the LED strips using L-Connect 3 for a unique setup. You can also sync your TL fans and apply the same lighting effect you like across all of them.

SMOOTH APPEARANCE
Cover the screws with anti-vibrate rubber pads for a seamless and uninterrupted aesthetic appeal.

SEAMLESS SOFTWARE
L-Connect 3 offers complete control over the UNI FAN TL series, including the lighting effects, fan speed, and LCD screen.

TWO FANS, ONE CONTROLLER
UNI FAN TL and TL LCD share the same controller, enabling the connection of up to 16 TL and TL LCD fans simultaneously, with a maximum of 9 TL LCD fans.

Fan Group Signal
Each port supports a maximum of 10 TL fans or 3 TL LCD fans

Performance

Suitable location: Computer case, Processor
Type: Fan
Fan diameter: 14 cm
Rotational speed (min): 400 RPM
Rotational speed (max): 1600 RPM
Noise level (high speed): 28.5 dB
Maximum airflow: 68.1 cfm
Maximum air pressure: 3.5 mmH2O
Bearing type: Fluid Dynamic Bearing (FDB)
Quantity per pack: 1 pc(s)

Design

Product colour: Black
Material: Liquid Crystal Polymer (LCP)
Number of fans: 1 fan(s)
Number of fan blades: 7
Feature: Illumination LED
Illumination colour: Multi
Fan connector: 4-pin
Display type: LCD
Display diagonal: 4.06 cm (1.6")
Display resolution: 400 x 400 pixels

Power

Power supply: 6.72 W
Voltage: 12 V
LED voltage: 5 V

Weight & dimensions

Width: 144 mm
Depth: 140 mm
Height: 28 mm
Fan dimensions (W x D x H): 144 x 140 x 28 mm
Fan thickness: 2.8 cm
