MSI Pro AP222T 13M-045EU

MSI Pro AP222T 13M-045EU. Product type: All-in-One PC. Display diagonal: 54.6 cm (21.5"), HD type: Full HD, Display resolution: 1920 x 1080 pixels, Touchscreen, Panel type: IPS. Processor family: Intel® Core™ i3. Internal memory: 8 GB, Internal memory type: DDR4-SDRAM. Total storage capacity: 256 GB, Storage media: SSD. On-board graphics card model: Intel UHD Graphics 730. Built-in camera. Operating system installed: Windows 11 Pro. Product colour: Black

Resilient and Pioneering
Spirit of Your Business
Your business should be empowered to stop at nothing while navigating your journey with the MSI Business & Productivity Series products.

Touch This World With Unlimited Opportunity
Intuitively clicking on what you need with your fingers, the PRO AP222T Series is equipped with in-cell touch technology that provides more flexibility and multiple uses.

Limitless Wireless Connection
MSI Cloud Center + Wifi
Fast, secure, and wireless backup & download between your PC and mobile devices. Transfer files, photos, videos, and more between your PC, Android, and iOS devices faster and easier than a cabled connection. You can make these files accessible to your family or team members, or you can also make files as private as you want. The decision is in your hands.

EASY MAINTENANCE DESIGN
With the HDD Rapid Upgrade Design, maintaining or upgrading your 2.5" storage on PRO AP222 Series will not be a nightmare any more.

Successful & Stylish B2B projects
Over the past years, MSI has successfully supported Countless of commercial projects, including government tenders, restaurant & hotel facilitation, shopping mall navigation projects, school & university developments and professional office projects.

Display

Display diagonal: 54.6 cm (21.5")
Display resolution: 1920 x 1080 pixels
Feature: Touchscreen
HD type: Full HD
Native aspect ratio: 16:9
Display brightness: 250 cd/m²
Panel type: IPS
Pixel pitch: 0.2745 x 0.2745 mm
Feature: Anti-glare screen

Processor

Processor manufacturer: Intel
Processor family: Intel® Core™ i3
Processor generation: Intel Core i3-13xxx
Processor model: i3-13100
Processor cores: 4
Processor boost frequency: 4.5 GHz
Performance cores: 4
Performance-core Max Turbo Frequency: 4.5 GHz
Performance-core base frequency: 3.4 GHz
Processor cache: 12 MB
Processor cache type: Smart Cache
Bus type: DMI4
Processor base power: 60 W
Maximum turbo power: 89 W

Memory

Internal memory: 8 GB
Internal memory type: DDR4-SDRAM
Maximum internal memory: 64 GB
Memory slots type: SO-DIMM
Memory clock speed: 3200 MHz
Memory layout (slots x size): 1 x 8 GB

Storage

Total storage capacity: 256 GB
Storage media: SSD
Total SSDs capacity: 256 GB
Number of SSDs installed: 1
SSD capacity: 256 GB
SSD interface: PCI Express
Feature: NVMe
Optical drive type: No
Feature: Card reader integrated

Graphics

Discrete graphics card model: Not available
Feature: On-board graphics card
On-board GPU manufacturer: Intel
On-board graphics card family: Intel® UHD Graphics
On-board graphics card model: Intel UHD Graphics 730

Audio

Feature: Built-in speaker(s)
Number of speakers: 2
RMS rated power: 4 W
Audio chip: Realtek ALC897

Camera

Feature: Built-in camera
Camera HD type: HD

Network

Feature: Wi-Fi
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Wi-Fi standards: Wi-Fi 6E (802.11ax)
WLAN controller manufacturer: Intel
WLAN controller model: Intel Dual Band Wireless-AC 9462
Antenna type: 1x1
Feature: Ethernet LAN
Feature: Bluetooth
Bluetooth version: 5.0

Ports & interfaces

Ethernet LAN (RJ-45) ports: 2
USB 2.0 ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
HDMI ports quantity: 1
Mini DisplayPorts quantity: 1
Headphone outputs: 1
Feature: DC-in jack

Design

Product colour: Black
Feature: VESA mounting
Panel mounting interface: 100 x 100 mm

Performance

Product type: All-in-One PC
Motherboard chipset: Intel H610

Software

Operating system installed: Windows 11 Pro

Processor special features

CPU configuration (max): 1

Power

AC adapter power: 120 W

Weight & dimensions

Width (with stand): 499.2 mm
Depth (with stand): 209.4 mm
Height (with stand): 373 mm
Weight (with stand): 5.9 kg
Package weight: 8.59 kg

Operational conditions

Operating temperature (T-T): 0 - 35 °C
Storage temperature (T-T): -20 - 60 °C
Operating relative humidity (H-H): 0 - 85%
Storage relative humidity (H-H): 0 - 90%

Certificates

Certification: FCC(Class B), CB/CE, UL(CUL), BSMI, VCCI, RCM(C-Tick)

Other features

HDMI in: 1
