ALLNET ALL-GHN102-bendraašis tiltas / kartotuvas

ALLNET ALL-GHN102-COAX. Networking standards: IEEE 802.1p, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u. Connectivity technology: Wired. Product type: Network bridge, Product colour: White. AC input voltage: 12 V, Power supply: 4 W. Certification: CE

With the G.HN Gigabit Ethernet Bridge ALL-GHN102-Coax, you can, with the existing TV cabling, expand your home network at home. There is no additional network wiring required. You can simply use the existing coax wiring in the wall. With the ALL-GHN102-Coax they can as quickly expand your network without rewiring and with little effort.

- up to 500 Mbps G.hn Port as Homenetwork-Backbone over TV-Wirering
- Two 100 / 1000Mbps Gigabit Ethernet Ports for Ethernet-Terminals (PC, Set-Top-Box, TV, WiFi-AP´s or other Ethernet-Devices with RJ45-Ethernetport...)
- Energyefficiency (green) Ethernet-Support
- Filter Built-in to Eliminate Noise from TV Signal Indication
- 6MHZ - 76MHz
- QoS Priority Mapping Support
- Tag VLAN Configuration
- IGMP Snooping Control
- Status and Statistic
- up to 15 devices possible

Network

Feature: Ethernet LAN
Networking standards: IEEE 802.1p, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u
Feature: Auto MDI/MDI-X

Ports & interfaces

Connectivity technology: Wired
Ethernet LAN (RJ-45) ports: 2
Feature: DC-in jack

Features

Product type: Network bridge
Product colour: White
LED indicators: Yes

Power

AC input voltage: 12 V
Power supply: 4 W

Operational conditions

Operating temperature (T-T): 0 - 50 °C
Operating temperature (T-T): -10 - 65 °F
Operating relative humidity (H-H): 10 - 95%

Certificates

Certification: CE

Weight & dimensions

Dimensions (WxDxH): 130 x 95 x 32 mm
