ASUS PRIME B760-PLUS Intel B760 LGA 1700 ATX pagrindinė plokštė
Prekės kodas:
6-90MB1EF0-M1EAY0
ASUS PRIME B760-PLUS Intel B760 LGA 1700 ATX pagrindinė plokštė
ASUS PRIME B760-PLUS Intel B760 LGA 1700 ATX pagrindinė plokštė
Prekės kodas:
6-90MB1EF0-M1EAY0
ASUS PRIME B760-PLUS Intel B760 LGA 1700 ATX pagrindinė plokštė
Jūsų palyginimo sąraše yra 3 prekės, prašome vieną pašalinti ir bandyti dar kartą.
- Įtraukti į patikusias prekes
- Pridėta į patikusias prekes
- Pašalinta iš patikusų prekių
Garantija
36 mėn.
Pristatymas iš Europos
per 6 - 11*
d. d.
| Compatible processor series | Intel® Core™ i7, Intel® Core™ i9, Intel® Core™ i3, Intel® Core™ i5, Intel® Celeron®, Intel® Pentium® Gold |
| Processor manufacturer | Intel |
| Supported processor sockets | LGA 1700 |
| Maximum number of SMP processors | 1 |
| Processor socket | LGA 1700 |
| Parallel processing technology support | Not supported |
| Windows operating systems supported | Windows 10 x64, Windows 11 |
| Audio output channels | 7.1 channels |
| Cooling type | Passive |
| Motherboard form factor | ATX |
| Motherboard chipset | Intel B760 |
| Motherboard chipset family | Intel |
| Power source type | ATX |
| ECC сompatibility | Non-ECC |
| Supported memory clock speeds | 5000, 6600, 6400 MHz, 6800, 5200, 4800 MHz, 6000, 6200, 7000, 5800, 5400, 5600, 7200 |
| Memory channels | Dual-channel |
| Unbuffered memory | Yes |
| Maximum internal memory | 192 GB |
| Number of memory slots | 4 |
| Supported memory types | DDR5-SDRAM |
| Memory slots type | DIMM |
| Depth | 244 mm |
| Width | 305 mm |
| Height | 36 mm |
| Ethernet LAN | Yes |
| Wi-Fi | No |
| Ethernet interface type | 2.5 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors | 2 |
| Front panel audio connector | Yes |
| EPS power connector (8-pin) | Yes |
| Peripheral (Molex) power connectors (4-pin) | 1 |
| USB 2.0 connectors | 2 |
| Thunderbolt headers | 1 |
| Number of SATA III connectors | 4 |
| CPU fan connector | Yes |
| ATX Power connector (24-pin) | Yes |
| Front panel connector | Yes |
| Number of COM connectors | 1 |
| TPM connector | Yes |
| Number of chassis fan connectors | 3 |
| S/PDIF out connector | Yes |
| 12V power connector | Yes |
| RGB LED pin header | Yes |
| BIOS type | UEFI AMI |
| Cables included | SATA |
| Supported storage drive interfaces | M.2, SATA III |
| RAID support | Yes |
| Supported storage drive types | HDD & SSD |
| RAID levels | 1, 5, 10 |
| Number of storage drives supported | 7 |
| Number of HDDs supported | 4 |
| DisplayPorts quantity | 1 |
| USB 2.0 ports quantity | 2 |
| HDMI version | 2.1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| HDMI ports quantity | 1 |
| DisplayPort version | 1.4 |
| Headphone outputs | 1 |
| VGA (D-Sub) ports quantity | 1 |
| Line-in | Yes |
| USB 3.2 Gen 2x2 Type-C ports quantity | 1 |
| PCI Express x1 (Gen 3.x) slots | 2 |
| Number of M.2 (M) slots | 3 |
| PCI Express x16 (Gen 4.x) slots | 1 |
| PCI Express x16 (Gen 5.x) slots | 1 |
| Weight | 760 g |
| Warnings | Before starting any maintenance or installation, disconnect the product from the power supply., Avoid direct contact with electronics to prevent electrostatic damage., Do not dispose of the motherboard in the ordinary rubbish bin; the product requires special disposal. |
